5x8 mm PU Hose Foldable Fitting Quick Coupler (Nitto Type)
modelo :
FFN-20P
FFN-20P
5x8 mm PU Hose Foldable Fitting Quick Coupler
(Nitto Type)
● Easy to operate and labor-saving with air connection.
● The body without air intake valve makes the air flow smooth and big.
● A built-in "lock mechanism" can prevents accidental disconnection.
● Remove the remain air on connection part before disconnection part before disconnection the plug.
● Low noise during plugging and unplugging.
● Material: Steel/ Zinc alloy
● Temp Range: -20~+80°C
● Thread: PT
5x8 mm PU Hose Foldable Fitting Quick Coupler
(Nitto Type)
● Easy to operate and labor-saving with air connection.
● The body without air intake valve makes the air flow smooth and big.
● A built-in "lock mechanism" can prevents accidental disconnection.
● Remove the remain air on connection part before disconnection part before disconnection the plug.
● Low noise during plugging and unplugging.
● Material: Steel/ Zinc alloy
● Temp Range: -20~+80°C
● Thread: PT
FFN-20P
5x8 mm PU Hose Foldable Fitting Quick Coupler
(Nitto Type)
5x8 mm PU Hose Foldable Fitting Quick Coupler
(Nitto Type)
● Packing: 120 pcs/CTN (N.W)14.2kg/ (G.W) 16.3kg /1.13' Cuft
|
Iteml No. |
Discription |
Size |
Net |
Max. |
Work |
Material |
|
- |
Inch |
(g) |
psi (bar/ Mpa) |
psi (bar/ Mpa) |
||
|
FFN-20P |
PU |
5x8mm |
118 |
290 (20/ 2) |
218 (15/ 1.5) |
Steel/ Zinc alloy |
FFN-20P
5x8 mm PU Hose Foldable Fitting Quick Coupler
(Nitto Type)
● Pneumatic Tools, Air Piping, Air Pressure Equipment.
5x8 mm PU Hose Foldable Fitting Quick Coupler
(Nitto Type)
● Pneumatic Tools, Air Piping, Air Pressure Equipment.
