Type

Two Stroke, Forced,Air Cooled, Single Cylinder

Displacement

46.5cc, ψ44x34mm(lnner bore size x stroke)

Fuel Tank Capacity

1 liter

Fuel Mixture Ratio

25：1(gasoline：2 cycle oil)

Revolution(idling)

≦2700rpm；Engagement Speed：≧3400

Revolution (loaded, impact)

7120 rpm

Revolution (non loaded, max)

8500 rpm

Naximum Output

2.03 Ps/6500 rpm

Naximum Torque

0.34 kg-m/5500 rpm

Compression Rate

7.4 : 1

Fuel Consumption Rate

520 g/kwh

Square Drive

1"  (25.4 mm)

Fastening Torque Range

406~1250 ft.ibs (550~1700 N.m)

Free Speed

1200 rpm

Bolt Capacity

1-5/8"  (M41)

Net Weight

39.6 lb  18 kg

Overall Length

L ：25-1/2" (647.7 mm)

H：10-3/4" (273.05 mm)

W：15" (381 mm)

Sound Pressure Level (LPA.d)

101 dB

Sound Ppwer Level(LWA.d)

112 dB

Vibration(m/s2)

8.0 m/s2

3PCS

5, 6, 8 mm Hex Key Wrench

1 PC

Spark Plug Wrench

1 PC

10-13 mm Spanner
